Tool Pro

The Tool Pro is a unique tool holding device for the assembly and disassembly of tapered V-flange tooling and modular tooling systems. Depressing the large gold button permits the adapter to rotate 360° and lock in 45° increments, allowing convenient access for all operations. Tightening torque for tool clamping can be applied in a downward motion, rather than horizontally, allowing the it to be installed on tool carts. Tools are simply lowered into the tool pot and automatically clamped into place with a spring loaded pin that locates into the V-groove of the tool holder. With the Tool Pro, you reduce damage to your expensive

tool holders, shanks and machine spindles while providing a safe working environment for your tool assembly operators —

advantages which pay off very quickly!

• HSK Type E/F, VDI and Polygon taper also available

Vario Quick-change system uses one permanently mounted base unit and

multiple adapters for different types and sizes of tool shanks.

• HSK Type E/F and VDI also available

100A 31.300.135

• Vario Spin adapters also available

Spin Full 360° radial tool rotation, while clamped,

permits easy access to large diameter tools

making it ideal for changing inserts on large

face mills without removing the tool from the

drive keys. Tools can be locked at increments

of 30° by engaging an index pin. The adapter NEW!NEW!

can also be rotated 360° and locked into any

position in increments of 45°.

Tool Pro Stand

Steep Taper HSK Taper

Safe and secure

tool assembly

31.300.500

• Polygon taper also available
