Dedicated Optics
View micro tools with increased magnification.
Catalog Description Number 32.299.157 Dedicated Optics, 1.5mm x 1mm 32.299.164 Dedicated Optics, 3mm x 2mm
Arm Extension
This extension allows for the camera system to go across
the spindle center line.
50mm
The measuring capacity of the X axis will be reduced
100mm in diameter & 50mm in radius.
100mm
The measuring capacity of the X Axis will be reduced of
200mm in diameter & 100mm in radius. Tool clearance
between the optic carrier will be 220mm maximum.
| Catalog Number | Description |
| 32.220.054 | Arm Extension 50mm – Snap Gage Principle |
| 32.220.055 | Arm Extension 100mm – Snap Gage Principle |
- The maximum space between the optic carrier is 220mm
