KOMBI GRIP
Innovative two-way clutch and needle roller clamping system ensures secure clamping at the tool flange periphery. Safe design eliminates any possibility of damage to the shank taper during the tightening process. øC Taper No. øM (x4) øP
CAUTION !
Kombi Grip must be securely fixed øD to a bench with 4 mounting bolts.
Catalog HSK No. Polygon
øC øD H øP øM
Number (Form A/E/F) Taper No.
| KG25R | 25 | — | 1.890 | 3.110 | 2.441 | ||
| 2.559 | |||||||
| KG32R | 32 | C3 | 2.165 | 3.346 | 2.717 | .276 M6 | |
| KG40R | 40 | C4 | 2.480 | 3.661 | 3.031 | or UNC 1/4 | |
| 2.756 | |||||||
| KG50R | 50 | C5 | 2.953 | 4.134 | 3.504 | ||
| KG63R | 63 | C6 | 3.465 | 4.862 | 2.953 | 4.154 | |
| KG80R | .354 M8 | ||||||
| 80 | C8 | 4.213 | 5.591 | 3.543 | 4.882 | ||
| or UNC 5/16 | |||||||
| KG100R | 100 | — | 5.000 | 6.378 | 3.937 | 5.669 |
- Mounting bolts (4 pcs.) must be ordered separately
øC Adapter Lock Screw
TOOLING MATE Taper No.øC Adapter Lock Screw W REPLACEABLE ADAPTER
Taper No. W P Tooling Mate is a tool assembly fixture with modular P Taper No. adapters accommodating different shank sizes. The Taper No.
simple, yet sturdy design eliminates any possibility øD øD
of damage to the taper shank during tool assembly/
Made of Special
| disassembly. Tooling Mate must be securely fixed | Made of Special Resin Material | øD | ||
| to a bench with 4 mounting bolts. | øM (x4) | Resin Material | øD |
øM (x4)
| Catalog Number | CV/BT No. | øC | øD | H | øW | øP | øM | Adapter Model |
| TMS40-30 TMS40-40 | 30 40 | 2.992 | 2.362 | 5.906 | 4.331 | 3.543 | .276 M6 | TMA40-30 TMA40-40 |
| TMS50-40 TMS50-50 | 40 50 | 4.134 | 3.465 | 7.480 | 6.299 | 5.118 | .354 M8 | TMA50-40 TMA40-50 |
Taper No. øC Adapter Lock Screw
Adapter W P CAUTION ! øM (x4) Tooling Mate must be securely fixed
to a bench with 4 mounting bolts.
Catalog HSK Polygon Adapter
øC H øW øP øM
| Number | No. | Coupling No. | Model | |||||
| TMS40-32R | 32 | C3 | TMA40-32R | |||||
| TMS40-40R | 40 | C4 | 2.992 | 6.496 | .276 M6 | TMA40-40R |
1 adapter is included 4.331 3.543
TMS40-50R 50 C5 or UNC 1/4 TMA40-50R
- Adapters can be ordered individually
| • Adapter Lock Screw is available as | TMS40-63R | 63 | C6 | 3.425 | 6.772 | TMA40-63R |
| a spare part (Model: RTM0615) | TMS50-80R | 80 | C8 | 4.488 | 8.465 | TMA50-80R |
- Mounting bolts (4 pcs.) must be .354 M8
ordered separately TMS50-100R 100 — 4.882 8.622 or UNC 5/16 TMA50-100R
