VARIO
Quick-change system uses one permanently mounted base unit
and multiple adapters for different types and sizes of tool shanks. Catalog Description Number 31.300.100 Base Unit
STEEP TAPER ADAPTERS HSK TAPER ADAPTERS POLYGON TAPER ADAPTERS
Catalog Type Catalog Type Catalog Type
Description Description Description
| Number | Taper Size | Number | Taper Size | Number | Taper Size |
| 31.300.110 | 30 | 31.300.130 | A32 | 31.300.153 | 3 |
| 31.300.111 | 35 | 31.300.131 | A40 | 31.300.154 | 4 |
| 31.300.112 | ISO Fixed 40 | 31.300.132 | A50 | 31.300.155 | C Fixed 5 |
| HSK Fixed | |||||
| 31.300.113 | 45 | 31.300.133 | A63 | 31.300.156 | 6 |
| 31.300.114 | 50 | 31.300.134 | A80 | 31.300.158 | 8 |
| 31.300.271 | 30 | 31.300.135 | A100 | 31.300.290 | 4 |
| 31.300.272 | 40 | 31.300.279 | A40 | 31.300.291 | 5 |
| ISO Spin | C Spin | ||||
| 31.300.273 | 50 | 31.300.281 | A50 | 31.300.292 | 6 |
| 31.300.274 | 60 | 31.300.283 | A63 | 31.300.293 | 8 |
| HSK Spin | |||||
| 31.300.284 | A80 | ||||
| 31.300.287 | A100 | ||||
| 31.300.288 | A125 | • HSK Type E/F and VDI also available |
SPIN
Full 360º radial tool rotation, while clamped, permits easy
access to large diameter tools, making it ideal for changing
inserts on large face mills without removing the tool from
the drive keys. Tools can be locked at increments of 30º by
engaging an index pin. The adapter can also be rotated 360°
and locked into any position in increments of 45º to further
improve ergonomic handling of any size and length of tool.
STEEP TAPER HSK TAPER POLYGON TAPER
Catalog Type Catalog Type Catalog Type
| Number | Taper | Size | Number | Taper | Size | Number | Taper | Size |
| 31.300.201 | 30 | 31.300.212 | A40 | 31.300.220 | 3 | |||
| 31.300.202 | 40 | 31.300.213 | A50 | 31.300.221 | 4 | |||
| ISO | ||||||||
| 31.300.204 | 50 | 31.300.214 | A63 | 31.300.222 | C | 5 | ||
| HSK | ||||||||
| 31.300.206 | 60 | 31.300.215 | A80 | 31.300.223 | 6 | |||
| 31.300.216 | A100 | 31.300.224 | 8 |
31.300.217 A125
