Measuring adapter	Clamping-Ø AW	Designation	Ident No.
	6 mm 2,5	T3-M0600	79.230.06
	8 mm 3,0	T3-M0800	79.230.08
	10 mm 4,0	T3-M1000	79.230.10
	12 mm 5,0	T3-M1200-SW5	79.230.12
	14 mm 5,0	T3-M1400-SW5	79.230.14
	16 mm 6,0	T3-M1600	79.230.16
	18 mm 6,0	T3-M1800	79.230.18
	20 mm 8,0	T3-M2000	79.230.20
	25 mm 8,0	T3-M2500	79.230.25
	32 mm 8,0	T3-M3200	79.230.32
Ferrite disc two-parts	For application with la shrinking shaft diame	rger cutting diameter ter	s as with the
	Clamping-Ø	Designation	Ident No.
	3,0 – 5,9 mm	ISGS3201GT-0	79.217.105
	6,0 – 12,0 mm	ISGS3201GT-1	79.217.205
	12,1 – 22,0 mm	ISGS3201GT-2	79.217.305
	22,1 – 32,0 mm	ISGS3201GT-3	79.217.405
Delivery disc	For the safe storage and shrunken tools	of the ferrite disc, basi	c tool fitting
		Designation	Ident No.
Cooling plate for machining tools	For depositing unshru	nken tools
		Designation	Ident No.
		T3-Z/WZ	79.236.100
Coil limit stop	Fixture used for spec pieces. Used as a sto no correct positioning front end will be poss	ial applications like fe pper for positioning th between ferrite disc ible.	rrite discs two- e coil when and chuck
		Designation	Ident No.
		ISGF3414	79.235.205
