Induction coilInduction coil for special applications
Only with an option “change coil”Clamping-Ø DesignationIdent No.
32-50 mm ISGS3200-279.203.002
32-50 mm (Inverse) ISGS3200-3.179.360.010
More special coils for different special tools a on requestre available
Ferrite discs TSFThe TSF set allows TSF chucks to be shrunk shrink machine. The TSF ferrite discs provide optimal shieldi magnetic field between coil and tool shank. This guarantees safe and reliable shrinking o chucks.using the ng of the f the TSF
TSF-Set Set ø3-2579.217.500
The TSF-Set consists of the following parts
Clamping-Ø DesignationIdent No.
Storage box
3 mm ISGS3201-TSF0379.217.503
4 mm ISGS3201-TSF0479.217.504
5 mm ISGS3201-TSF0579.217.505
6 mm ISGS3201-TSF0679.217.506
8 mm ISGS3201-TSF0879.217.508
10 mm ISGS3201-TSF1079.217.510
12 mm ISGS3201-TSF1279.217.512
14 mm ISGS3201-TSF1479.217.514
16 mm ISGS3201-TSF1679.217.516
18 mm ISGS3201-TSF1879.217.518
20 mm ISGS3201-TSF2079.217.520
25 mm ISGS3201-TSF2579.217.525
TER / Clamping -ØDesignationIdent No.
TER16 / 3 – 4 mmISGS3201-TER16-179.217.TER16-1
TER16 / 6 – 8 mmISGS3201-TER16-279.217.TER16-2
TER20 / 6 – 10 mmISGS3201-TER20-179.217.TER20-1
TER25 / 3 – 4 mmISGS3201-TER25-179.217.TER25-1
TER25 / 6 – 10 mmISGS3201-TER25-279.217.TER25-2
TER25 / 12 – 16 mmISGS3201-TER25-379.217.TER25-3
TER32 / 6 – 8 mmISGS3201-TER32-179.217.TER32-1
TER32 / 10 – 20 mmISGS3201-TER32-279.217.TER32-2
