exaCT L exaCT L

WENZEL exaCT	L 225
NON-DESTRUCTIVE MEASURING & TESTING
The exaCT L offers a simpliﬁ ed, cost-effective and com-	automatically optimized by the system. In its performance
pletely automated workﬂ ow for the entire CT analysis	class, the exaCT L is one of the most compact computed
process. Due to its high X-ray performance in combination	tomographs on the market. It has three independent axes
with a fast detector, the exaCT L enables the measure-	and offers an impressive X-ray performance. Hardware
ment and inspection of components in a short time. Due	and software offer the possibility of automated inte-
to the intuitive user guidance, exact measurement results	gration into the production line and are the appropriate
can allready be generated after a short training period.	answer to questions regarding Industry 4.0 solutions.

The exaCT L thinks ahead: Measuring parameters are

P		1	11 11 10 10 9 9 8 8 7 7 6 6 5 5 4 4 3 3 2 2 1 12	12
Large measuring volume of 300 mm in height and 235 mm in diameter				AT A GLANCE
P	A	A	L B	A	A
P Fast and robust detector optimized for short CT scans and long lifetime
Three independent travel axes for high speeds and short measuring and testing times	B	B		B	B
P				Best results through high performance
			P
				Fast scanning \| Fast reconstruction \| Fast evaluation
	C	C		C	C
			H
APPLICATIONS			P One scan, many evaluations, maximum time
	D	D		savingDD
				Metrology with virtual CMM \| NDT and failure analysis
	E	E		E	E
The exaCT L is widely applicable and is able to scan even large components with high densities due to its large mea-			P High efﬁ ciency due to small space
suring volume. It is best suited for measuring and testing parts made of plastic, light metal, composite materials or				reqiurements
	F	F	MASCHINENPROFIL	F	F
multi-materials.				Large measuring volume \| Suitable for workshops \|
				Automation solutions
	G	G		G	G

P High ﬂ exibility

Metrology Assembly inspection Defect analysis
