pneumatically activated axis movement� movimento assi attivato pneumaticamente
fine adjustment X & Z axis� comandi micrometrici assi X e Z
high precision ISO 50 integral spindle� mandrino integrale ISO 50 di alta precisione
spindle brake� freno mandrino
integrated calibration master� tacca di calibrazione integrata
spindle concentricity1µm concentricità mandrino
axis resolution1µm risoluzione assi
universal spindle� mandrino universale
adapter quick change system� cambio rapido equipaggiamenti
universal tool-holder clamping system F20 integrated i� bloccaggio universale portautensili F20
shrink-fit system i� shrink-fit system
45X standard magnification� ingrandimento 45x
episcopy front light system� episcopia integrata
CNC unit for X, Z, A e Yunità CN per assi X, Z, A e Y
autofocus spindlemandrino autofocus
EDGE Pro control� unità di controllo EDGE Pro
Post ProcessorPost Processor
integration to CAM and TMSintegrazione CAM e TMS
Integration with RFID systemsintegrazione con sistemi RFID
power supply (V)3x400+N alimentazione (V)
power consumption (KVA)10 potenza (KVA)
pneumatic requirements (Mpa)0.5 ÷ 0.7 consumo aria

standard option

STP 44STP 46STP 48STP 64STP 66STP 68STP 84STP 86STP 88
max Ø400400400600600600800800800
max H400600800400600800400600800
W170017001700170017001700170017001700
L146014601460146014601460151015101510
H189020902290189020902290189020902290
shrink stroke600600800600600800600600800
dimensions in mm/dimensioni in mm
