ACCESSORIES REDUCTION ADAPTER Catalog Type Automatic Integrated Clamping Number Loss in Z Outer Taper Inner Taper Adapter will simultaneously clamp to the tool 32.310.100 ISO 40 as it is clamped to the spindle. The adapter has 32.310.101 ISO 30 ISO 50 an integrated calibration notch with calibration -35mm 32.310.102 ISO 45 values etched onto the side plate. 32.310.103 ISO 40 ISO 30 • Requires automatic clamping system 32.310.110 HSK-40A/C 32.310.111 HSK-50A/C 32.310.112 HSK-63A/C -80mm 32.310.114 HSK-80A/C 32.310.116 ISO 50 HSK-80FM 32.310.119 C3 32.310.120 C4 -80mm 32.310.121 C5 32.310.122 C6 SPERONI STEEP TAPER / HSK Catalog Type Catalog Type MANUAL CLAMPING REDUCTION ADAPTER Number Outer Taper Inner Taper Number Outer Taper Inner Taper Integrated clamping system 32.110.001 HSK-32A/C 32.110.010 HSK-50F ensures secure and repetitive 32.110.001.1 HSK-32E 32.110.011 HSK-63A/C clamping. The design allows for 32.110.002 HSK-32F 32.110.012 HSK-63B/D tool holder clamping without 32.110.003 HSK-40A/C 32.110.013 HSK-63E having to remove the coolant tube. 32.110.004 HSK-40B/D 32.110.014 ISO 50 HSK-63F Supplied with a precision ground ISO 50 32.110.005 HSK-40E 32.110.019 HSK-100A/C calibration notch with calibration values etched onto the side plate. 32.110.006 HSK-40F 32.110.020 HSK-100B/D 32.110.007 HSK-50A/C 32.110.021 HSK-100E 32.110.008 HSK-50B/D 32.110.022 HSK-100F 32.110.009 HSK-50E • For pull stud ISO50 32.110.031 SPERONI STEEP TAPER STEEP TAPER NO CLAMPING REDUCTION ADAPTERS NO CLAMPING REDUCTION ADAPTER Supplied with a precision ground calibration notch with Designed with zeroing/calibration values etched on calibration values etched onto the side plate. A full taper the sleeve plate. Drop-in design used for accurately allows for more spindle contact. Drop-in design used for measuring Z (length). accurately measuring Z (length) and X (diameter and runout). Catalog Type Catalog Type Number Outer Taper Inner Taper Number Outer Taper Inner Taper 31.330.002 ISO 25 32.310.094 ISO 25 31.330.003 ISO 30 32.310.095 ISO 30 31.330.004 ISO 50 ISO 35 32.310.096 ISO 50 ISO 35 31.330.005 ISO 40 32.310.097 ISO 40 31.330.006 ISO 45 32.310.098 ISO 45 Taper according to ISO 7388 Precision Ground Taper Angle Tolerance AT1 50 SPERONI from BIG KAISER
