FUTURA CNC

HH

WW LL

Catalog NumberDescriptionX-Axis Max øZ-Axis Max LengthPowerConsumptionPneumatic RequirementsLWHWeight
32.220.000.CNCFUTURA STP 44 CNC16.0 (400mm)51.0 (1295mm)63.0 (1600mm)74.0 (1880mm)1215 lbs (550 kg)
32.220.011.CNCFUTURA STP 46 CNC16.0 (400mm)24.0 (600mm)51.0 (1295mm)63.0 (1600mm)82.0 (2082mm)1260 lbs (570 kg)
32.220.012.CNCFUTURA STP 48 CNC32.0 (800mm)51.0 (1295mm)63.0 (1600mm)90.0 (2286mm)1300 lbs (590 kg)
32.220.013.CNCFUTURA STP 64 CNC16.0 (400mm)51.0 (1295mm)63.0 (1600mm)74.0 (1880mm)1300 lbs (590 kg)
32.220.014.CNCFUTURA STP 66 CNC24.024.0 (600mm)51.0 (1295mm)63.0 (1600mm)82.0 (2082mm)1345 lbs (610 kg)
32.220.015.CNCFUTURA STP 68 CNC(600mm)32.0 (800mm)51.0 (1295mm)63.0 (1600mm)90.0 (2286mm)1390 lbs (630 kg)
32.220.016.CNCFUTURA STP 612 CNC48.0 (1200mm)100V (60Hz up to 5 AMPs)51.0 (1295mm)63.0 (1600mm)106.0 (2692mm)1435 lbs (650 kg)
32.220.017.CNCFUTURA STP 84 CNC16.0 (400mm)110V (60Hz up to 5 AMPs)1…2 cfm70-100 psi (.05-.07 bar)53.0 (1345mm)63.0 (1600mm)74.0 (1880mm)1345 lbs (610 kg)
32.220.018.CNCFUTURA STP 86 CNC32.024.0 (600mm)220V (60Hz up to 3 AMPs)53.0 (1345mm)63.0 (1600mm)82.0 (2082mm)1410 lbs (640 kg)
32.220.019.CNCFUTURA STP 88 CNC(800mm)32.0 (800mm)53.0 (1345mm)63.0 (1600mm)90.0 (2286mm)1455 lbs (660 kg)
32.220.020.CNCFUTURA STP 812 CNC48.0 (1200mm)53.0 (1345mm)63.0 (1600mm)106.0 (2692mm)1500 lbs (680 kg)
32.220.021.CNCFUTURA STP 124 CNC16.0 (400mm)61.0 (1550mm)63.0 (1600mm)74.0 (1880mm)1585 lbs (720 kg)
32.220.022.CNCFUTURA STP 126 CNC48.024.0 (600mm)61.0 (1550mm)63.0 (1600mm)82.0 (2082mm)1630 lbs (740 kg)
32.220.023.CNCFUTURA STP 128 CNC(1200mm)32.0 (800mm)61.0 (1550mm)63.0 (1600mm)90.0 (2286mm)1675 lbs (760 kg)
32.220.024.CNCFUTURA STP 1212 CNC48.0 (1200mm)61.0 (1550mm)63.0 (1600mm)106.0 (2692mm)1765 lbs (800 kg)

*Please specify power supply choice of 100V, 110V or 220V when ordering ACCESSORIES

  • Use of battery backup is recommended
  • Standard integral spindle is ISO 50 taper; other options available
  • Standard control software is SIMPLE VISION; upgrades available
• 1-year warranty on material, control, labor and travel expensesSOFTWARE BATTERY
• 3-year warranty on DELL PCSPINDLE OPTIONS OPTIONS ADAPTERS BACKUP
