Operating the ISG3410

4.3 Switching on the device

• Switch on the main switch

The display shows the type of the machine. Now you are in the main menu.

Shrinking Configuration Service

The ISG3410-TWK/ -TLK is ready for use now.

At ISG3410-WK please note: After selecting Shrinking or Service and pressing the OK button, the compressed air is switched on.

The linear unit moves down initially and then upwards. If no coil is fitted, the carriage quickly moves upward due to the lack of weight!

The same time, also the lifting unit moves down first and then up again.

The ISG3410-WK is at home position and ready for use now.

4.4 Switching off the device In order to avoid damage, the unit must not be switched off when the coil is raised. The unit must be switched off as follows:

• Remove the chuck from the location
• Lower the coil by continuous pressing of the Stop button (ISG3410-WK)
• Switch off at the main switch
