Tangential drive for very lightweight rotors Balancing of permanent magnet armatures Belt drive from above for balancing
such as non-ferrous armatures (Pasio 05)with 3 drive belts (Pasio 5)of radial fans (Pasio 5)
Calibration runs unnecessaryyou can process very light precision components such as
With the PASIO 5 and 05, no calibration runs are requiredelectric motors and spindles for the textile and machine
during the complete balancing process. These two modelstool industry. Rotors in the standard range from 1 – 5 kg
are permanently calibrated, so that the measuring run canare balanced with a universal belt drive.
be started immediately after entering the geometric data.
Proven measuring technology
With the PASIO 005, a short calibration run is importantThe PASIO 5 series comes complete with proven measur-
for even greater accuracy due to the required precision.ing technology in the accustomed Schenck top quality in
The measuring units guide the user simply and quicklytwo levels:
through the individual steps, so that balancing can be
started within a few minutes.The CAB 920 SmartTouch combines maximum precision
with simplest operation: the CAB 920 offers an ingenious-
Variable drive technology for great flexibilityly simple operating concept, whose logical relationships
Wherever it is used, it works with the maximum flexibility,are clearly apparent at the first glance. The result is totally
providing weighty advantages even in the case of lightconvincing: rapid and safe working with the minimum
rotors. The PASIO 5 series is your flexible partner in thelearning requirement – for every conceivable technical ro-
workshop and laboratory, in repair operation or also fortor variant.
small series production. The benefits: it balances very
small rotors from a few grams up to 5 kg. This is madeThe CAB 820 is the basic measuring unit, which sets the
possible by the variable drive technology with which westandards for its class. It offers absolute peak performance
have equipped the machine. For small and miniaturecombined with every operating convenience, all at out-
Easy setup of the laser scanning Discover the versatility rotors, a belt drive with an elastic drive belt is used. Instanding value for money. This measuring unit is always
head for an even more accurate combination with prism bearings, this achieves the maxi-the right solution when you want to achieve the balancing
angle position (Pasio 005) mum measuring sensitivity. This means for example thatobjective in your business quickly and without major effort.

Convincing precision technology The PASIO 5 series shows its strengths even when setting up. With the built in line laser, you can set up the machine for the rotor quickly and faultlessly. All values are saved, and are therefore also available again at any later time for rotors of the same type. The new laser scanning head is easy to adjust and so offers even more accurate angle position – a simple mark on the rotor in a contrasting colour is often enough for a reliable measurement. The machine registers the position of the different reference marks. The automatic angle positioning on the correction points enables an exact and fast unbalance correction on all models. The measurements remain reliably accurate even in the case of magnetised rotors such as permanent magnet armatures. Due to the anti-magnetic material of the PASIO 5 series it avoids undesired feedback effects, and therefore distorted measurement results.

6The line laser ensures the clear display CAB 920 the top level measuring unit – CAB 820: The basic measuring unit for 7
of the measurement planes (Pasio 5)with easy operation and peak performaceoutstanding accuracy with clear displays
