SETTING SLEEVES
Available in metric and inch, setting sleeves are offered in a range of diameters depending on the tool holder's size
and tool shank size. Each sleeve is precision ground and marked for easy recognition.
INCH SET
Catalog Description Qty. Number
32.316.201 Inch 9 Pcs
- Includes the following sizes:
3/16", 1/4", 3/8", 1/2", 5/8", 3/4", 7/8", 1", 1¼"
METRIC SET
Catalog Description Qty. Number
32.316.000 Metric 10 Pcs
- Includes the following sizes:
6mm, 8mm, 10mm, 12mm, 14mm, 16mm, 18mm, 20mm, 25mm, 32mm
COOLING SLEEVES
Available in metric and inch, cooling sleeves are offered in a
range of diameters and taper degree depending on the tool
holder's size and tool shank size.
3º SET 4.5º SET
- Includes the following sizes:
- Includes the following sizes:
| Catalog | Metric — 5mm, 6mm, 8mm, 10mm, 12mm, 14mm, | Catalog | Metric — 6mm, 8mm, 10mm, 12mm, 14mm, 16mm, | ||
| Number | 16mm, 18mm, 20mm, 25mm | Number | 18mm, 20mm | ||
| Inch — 3/16", 1/4", 3/8", 1/2", 5/8", 3/4", 7/8", 1", 1¼" | Inch — 1/4", 3/8", 1/2", 5/8", 3/4", 7/8" | ||||
| 32.316.110 | • Extra large cooling sleeves available upon request | 32.316.111 | • Extra large cooling sleeves available upon request |
INDUSTRIAL POWER TRANSFORMER
Catalog Description Convert your plant's 220, 440, 460 or 480 volt Number
3 phase power to the 400 volt 3 phase power that 32.316.900 Power Transformer
is required for SPERONI FUTURA AUTOSHRINK.
