Термоусадочные машины Pokolm серии TSI 3510
OPERaTION dISPLaY, TECHNICaL daTa
Comfortable operation display
| u | Colour display | u | Selection of shrinking mode with |
| u | Easy selection by pictograms | preinstalled arbor parameters |
u intuitive machine operation u language independent
u Selection of shrinking diameter u Displaying parameter, processing
status and required ferrite disc
Technical data
| Name | TSI11000WKT | TSI11000WKS |
| output | 1 | 1 kW |
| System voltage | 400 V, | 50 Hz, 16 A |
| Cooling | Flui | d cooling |
| Compressed air | - | 4 bar (dried, nonlubricated, filtered) |
| max. machine interface | HSk25 - HSk100 | , Sk/BT30 - Sk/BT50 |
| Contour-independent cooling | Yes | |
| Cooling time | ~ | 20 - 40 s |
| Fluid tank | ~ 25 l | ~ 50 l |
| Dimensions | W 800, D 560, H 1130 mm | W 800, D 560, H 1720 mm |
| Clamping range Solid Carbide | Ø 3 - | 32 mm |
| Coil | fixed, Ø | 54 mm |
| max. tool length | 400 mm in | the HSk63 |
| max. cooling length | 160 mm in | the HSk63 |
| Weight | ~70 kg | ~120 kg |
on request, the induction shrinking station TSI11000WkS is also available in a version with a replaceable exchange-coil for large clamping diameters up to 50 mm.
