LH Gantry SeriesLH Gantry Series PRODUCT RANGE CMM
WENZEL LH GANTRY SERIES
PRECISE RESULTS WHEN MEASURING LARGE COMPONENTS
The LH Gantry is a CNC coordinate measuring machinenot require a separate foundation. Thermal environmental
with air bearings in all axes. It offers all the advan-infl uences affecting the workpiece and the CMM can be
tages and application possibilities of the LH Series andcorrected by means of automatic temperature compensa-
has also been specially designed for the inspection oftion (optional). The optional use of a rotary table means
large-volume and heavy workpieces. The raised guidesthat even large rotationally symmetrical components can
in the Y-axis also ensure maximum stability and rigidity,be measured fl exibly and accurately. LH Gantry series
even with dynamic movements. Overall, the machinemeasuring machines are available in Standard, Premium
body forms an inherently stable, homogeneous unit withand Premium Select accuracy classes.

optional integrated active vibration damping, which does FEATURES P Long-term stability and high mechanical precision due to granite machine structure P Homogeneous machine structure and integrated vibration damping (optional), no need for a separate foundation

P Highest stiffness and stability due to high drive, bearing and guide components in the Y-axis High dynamics due to double drive (LH 2015 / LH 2317) in the Y-axis and backlash-free friction drives MEASURING ACCURACY P P High wear resistance and freedom from residual stress due to robust granite design

P Maintenance-friendly thanks to maximum spare parts availability and easily accessible replacement components Volumetric length measuring uncertainty E (µm)

TypeMeasuring ranges X x Y x Z (mm)Volumetric length measuring uncertaintyEL, MPE (µm) Premium Select
LH 20152000 x 3000/4000/5000 x 15002,8 + L / 450
LH 23172300 x 4000/5000/6000 x 17503,0 + L / 450

Stable, reliable and fully dynamic, LH Gantry machines are universally and fl exibly applicable for a wide range of applications. Typical areas of application are, for example, the measurement of large engines, large gears or heavy machine components.

LH 2015 LH 2317

Value E is only valid with the respective touch probe. Further information can be found in the technical data sheets. Other Y-lengths on request. Subject to changes in design and scope of delivery as well as further technical development.L, MPE

YOUR ADVANTAGES AT A GLANCE

P Air bearing guide elements in all axes P Versatile sensor options

High mechanical precision | Granite base | Handcrafted Switchable sensor systems | 3- or 5-axis scanning | Optical sensors

P Low operating costs

Low air consumption | Reliable and inexpensive P Ergonomic design spare parts Simple operation | Simple maintenance | No foundation necessary

P High fl exibility

Customer-specifi c measurement volume | Data compatibility with other WENZEL systems |
