LH series - gantry measuring machinesCT series - Non-destructive work piece testing
In all imaginable branches of industry, the air-bearingAdditive manufacturing processes with their possibilities
portal measuring machines of the LH series from WENZELto produce internal complex structures unreachable by
with their high precision, long-term stability, reliability andconventional measuring tools are to be found more and
flexibility to have the ability improve products. From smallmore in production applications. WENZEL’s CT range is
to medium measuring volumes, as bridge machines andthe ideal tool for measuring and testing these internal
typically gantry machines for larger measuring rangesand external structures of objects without contact and in
up to very large machines with guide beams on concretenon-destructive testing. Defect and structural analyses as
foundations, the machines are produced to the highestwell as assembly and dimension checks to the highest
quality standards in many sizes and also customer-spe-precision of non-visible and accessible component areas
cific oversize lengths, designs and equipment.in a short time paired with a high information density of
the volume data characterize this series of machines.
SF series – Shop floor measuring machineCORE Series - Optical high-speed scanning of reflec-
Measurement results should be delivered faster andtive components
closer to the production line. Accordingly, WENZEL offersThe CORE measuring machine with turntable and the
the SF 1210, SF 87 and SF 55 special shop floor machinesoptical double-eye sensor is unmatched for fast mea-
that are built for the rough environmental conditions insurement of shiny components such as turbine blades,
production and at the production line and are also ideallyartificial knee and hip joints and when scanning other
suited for both operator use and automation.rotationally symmetric, measurable from the outside

parts in conjunction with the optional, additional tactile sensor for other geometries. R series - Horizontal measuring machines The proven upright machines of the R series from

WENZEL not only appear in automotive industry and transport engineering, but also in model and mold making, in the aerospace industry as well as in heavy and special machine construction. The systems with and without base plate, integrated into a foundation on the ground level or mounted on an existing floor, are configured not only in customer-specific axis lengths but also as multiple and multi-stand systems or with underfloor measuring equipment.

Depending on the type and equipment, WENZEL offers the machines, the right sensors: changeable probing and styli. Proven over decades, the undisputed world bestseller PH10, the stepless PH20, the revolutionary high-performance REVO head and optical and roughness sensors from Renishaw are availlable. The systems are completed with the appropriate user-friendly software - “Made by WENZEL” -for measuring, evaluating, reverse engineering and for machine monitoring. Of course, all machines are equipped with interfaces and can be equipped for automation and data input and output and can thus be integrated into a fully automatic process. All WENZEL systems are characterized by maximum mechanical precision, reliability and future-proofing through long-term stability and upgradeability. In addition to the in-house service for installation and maintenance, WENZEL offers a comprehensive training program in the training center, including the AUKOM Training Center and training of machine operators. Even before the project starts, WENZEL advises not only on the design of the measuring technology itself, but also on the planning of premises, any necessary foundations, automation and networking the measuring machine as well as subsequently during the creation of the measuring program. Thus, WENZEL is the right partner right from the start to solve your measuring task.
